Aritco Access Lift
Aritco Access Lift
Aritco Access Lift
ACCESSIBILITY FOR HOME & PUBLIC BUILDINGS
Aritco Access Lift is designed to make your home as well as public and commercial buildings accessible for everyone. Practical and smart with sizes for all needs. The lift expresses Scandinavian design and features a backlit panel and lit handlebar. With an option to personalize it with details such as glass walls, a range of various colors and different materials.
YOU CAN CHOOSE BETWEEN 3 DIFFERENT CONTROL PANELS.
.jpg)
1. HOME VERSION (A)
The control panel is with 32 mm. blank destination buttons. As identification for each floor an own text (max 10 signs) is written directly on the control panel. The touch plate of the buttons in neutral/flat and in matted stainless steel. 6 buttons/floor possible for all combinations, except for when having landing indicator and key lock on the control panel, then 5 buttons/floor are possible.
2. ACCESSIBILITY VERSION (ฺB)
The control panel is with 32 mm. buttons with text/numbers and braille. Following buttons are available: -2, -1, 0, 1, 2, 3, 4, 5, 6, 0A, 0B, 1A, 1B, 2A, 2B, 3A, 3B, BG, E, G, K, U, B The touch plate of the buttons is in aluminum, black anodized (AlMg3 EV6). Text/number embossed. Height of text/number 15 mm. With Braille. 6 buttons/floors possible for all combinations, except for when having landing indicator and key lock on the control panel, then 5 buttons/floors are possible.
3.LARGE ACCESSBILITY VERSION (C)
The control panel is with 50 mm. large buttons with text/numbers and braille. With the large buttons you have the possibility to provide enhanced accessibility. Often used in hospitals. Following buttons are available; -2, -1, 0, 1, 2, 3, 4, 5, 6, 0A, 0B, 1A, 1B, 2A, 2B, 3A, 3B, BG, E, G, K, U, B The touch plate is in stainless steel in black. Text/number embossed. Height of text/number 30.3 mm
KEY FEATURES
TECHNICAL SPECIFICATIONS
OUR MOST VERSATILE HOME LIFT
Aritco Access Lift is designed to make public and commercial buildings accessible for everyone. The lift expresses Scandinavian design and features a backlit panel and lit Aritco Access Lift is designed to make your home as well as public and commercial buildings accessible for everyone. Practical and smart with sizes for all needs. The lift expresses Scandinavian design and features a backlit panel and lit handlebar. With an option to personalize it with details such as glass walls, a range of various colors and different materials.
